| Features |
|---|
| IPS Screen |
| IPX7 Waterproof Level |
| Bluetooth Touchless Unlocking |
| UART/CAN Communication Protocol |
| Tempering Glass |
| 26K Ture Color |
| Navigation System Screen Projection |
| Colorful Animation UI |
| Technical Specifications | |
|---|---|
| Size (Mm) | 86.8*50.5*12.5 |
| Screen Size (Inch) | 2.4” |
| Installation Diameter | φ22.2/25.4 |
| Screen Type | IPS Full Viewing Angle Screen |
| Screen Color | RGB |
| Screen Resolution | 320*240PX |
| Connector Type | M5 Waterproof Connector |
| Connector Length (Cm) | 20 |
| Voltage (V) | 12/32/48/60 |
| Operating Temperature (℃) | -20-+70 |
| Ingress Protection Ratings | IPX7 |
| Weight (G) | 67 |
| Communication Protocol | UART/CAN |
| Bluetooth | 4.0+BLE |
| Type-C Port | Supported |
| Display Content |
|---|
| Current Speed |
| MAX Speed |
| Average Speed |
| Single Trip Distance |
| Odometer |
| Battery Remaining Rideable Distance |
| Error Code Indication |
| Battery Level Indicator |
| Push-Assistance Mode |
| Parameter Settings |
|---|
| Backlight Brightness Setting |
| Miles/Kilometers Switching Settings |
| Speed Limit Setting |
| Wheel Diameter Setting |
| Battery Voltage Switching |
| Auto Sleep Time |
| Factory Reset |
| Password Setting |
| English/European/Southeast Asian Languages Select, etc. |
| Supported Certificate |
|---|
| IPX7 |
| CE |
| RoHS |
