| Technical Specifications | 2B: Aluminum Sensor Body 5V
2C: Steel Sensor Seat 5V 2D: Aluminum Sensor Seat 3.3V 2E: Steel Sensor Seat 3.3V |
|---|---|
| Operating Principle | Torque Sensor |
| Voltage | 5V |
| Torque Output Voltage Range (DCV) | 0.7~4.8V |
| ZTV origin voltage | 0.7±0.15V |
| Torque signal slope | 35mv/N.m |
| Cadence Signal (signal/cycle) | 32/36 |
| Duty Ratio | 50% |
| Axostyle | JIS |
| Color | Black |
| Weight | 0.43kg(68/148mm) |
| Operating Temperature | -20 ~ 85℃ |
| IP | IP57 |
| Certificate | EN15194: 2017, ISO13849-1 |
| patent | Chinese patent |
